Belaz 68020
- Weight:
- 30.8 t
- Transport length:
- 8.45 m
- Transport width:
- 2.99 m
- Transport height:
- 3.95 m
68020 Belaz 68020 Specifications & Technical Data (2020—2026)
Technical specs - 68020 Belaz
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 30.8 t
- Transport length
- 8.45 m
- Transport width
- 2.99 m
- Transport height
- 3.95 m
- Standard tyres
- 26.5-25 НС32
- Travel speed
- 34.6 km/h
- Reverse travel speed
- 31.1 km/h
- Front blade width
- 4.2 m
- Transmission type
- HY
- Model series
- 68020
- Engine manuf.
- Cummins
- Engine type
- QSM11
- Engine power
- 250 kW
- Displacement
- 10.8 l
- Revolutions at max torque
- 2100 rpm
- Max. torque
- 1674/1400 Nm
- Cylinder bore x stroke
- 125x147 mm
- Emission level
- EU Stage III
More technical details, like: blade type, soil pressure, max. drawbar pull, dimension lxwxh, no. of cylinders are available in the full technical specs.
Special equipment
- Diesel particulate filter
-
No
- Rear ripper
-
No
- Tilt device
-
No
- Aircondition
-
No
