M525 Menzi excavator specs & dimensions (2020 - 2021)

Weight: 11t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.96m – Transport width: 2.37m – Transport …

Weight: 11t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.96m – Transport width: 2.37m – Transport height: 2.55m

Check out detailed specifications, information and technical data for Menzi M525 excavator manufactured between 2020 - 2021. Get more in-depth insight with Menzi M525 digger specifications. See information, like: Weight: 11t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.96m – Transport width: 2.37m – Transport height: 2.55m and more.

Walking Excavators Menzi M525
Walking Excavators Menzi M525
Walking Excavators Menzi M525
Walking Excavators Menzi M525
Walking Excavators Menzi M525
Walking Excavators Menzi M525
Walking Excavators Menzi M525
Walking Excavators Menzi M525

Technical specs - M525 Menzi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
11 t
Standard tyres
600/50-22.5
Bucket capacity
0.4 m³
Transport length
5.96 m
Transport width
2.37 m
Transport height
2.55 m
Max. Reach horizontal
8.21 m
Dredging depth
5.47 m
Tear-out force
69 kN
Bucket width
0.6 m
Model series
M
Engine manuf.
Deutz
Engine type
TCD4.1 L4
Engine power
115 kW
Displacement
4.04 l
Revolutions at max torque
1500 rpm
Max. torque
609/1500 Nm
No. of cylinders
4
Cylinder bore x stroke
101x126 mm
Emission level
EU V

Basic model incl. ROPS cabin, standard boom and standard bucket

Special equipment

Overload alert
Yes
Central lubrication
Yes
Aircondition
Yes
