M325 Menzi excavator specs & dimensions (2013 - 2019)

Name: Menzi M325 Walking Excavators
Brand: Menzi

Weight: 8.8t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.5m – Transport width: 2.35m – Transport …

Weight: 8.8t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.5m – Transport width: 2.35m – Transport height: 2.55m

Check out detailed specifications, information and technical data for Menzi M325 excavator manufactured between 2013 - 2019. Get more in-depth insight with Menzi M325 digger specifications. See information, like: Weight: 8.8t – Standard tyres: 600/50-22.5 – Bucket capacity: 0.4m³ – Transport length: 5.5m – Transport width: 2.35m – Transport height: 2.55m and more.

M325

Years of manufacture: 2013—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - M325 Menzi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.8 t

Standard tyres: 600/50-22.5

Bucket capacity: 0.4 m³

Transport length: 5.5 m

Transport width: 2.35 m

Transport height: 2.55 m

Max. Reach horizontal: 7.77 m

Dredging depth: 5 m

Tear-out force: 54 kN

Bucket width: 0.6 m

Model series: M

Engine manuf.: Deutz

Engine type: TCD3.6 LA

Engine power: 90 kW

Displacement: 3.6 l

Revolutions at max torque: 1600 rpm

Emission level: 3b

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, total number of dippers - mono, emission rating, engine manufacturer, engine model, rated speed, engine output - net, transmission type, number of tyres - standard, tyre size - standard, transport height - over mono boom, overall width, machine width - maximum, tailswing radius, cab height, overall width - stabilisers down, standard dipper length, maximum dig height - mono boom, dump clearance height - mono boom, dig depth - mono boom, fuel tank, slew speed, max bucket breakout, mono boom, number of main pumps, main pumps - maximum flow, boom pressure are available in the full technical specs.

Basic model incl. ROPS cabin, standard boom and standard bucket

Special equipment

Overload alert: Yes
Central lubrication: No
Aircondition: No

Download datasheets (PDF)

M325 Menzi Specification for Europe (DE)
