M220 Menzi excavator specs & dimensions (2016 - 2020)

Weight: 7.5t – Standard tyres: 500/45-20 – Bucket capacity: 0.4m³ – Transport length: 4.78m – Transport width: 2.2m – Transport he…

Weight: 7.5t – Standard tyres: 500/45-20 – Bucket capacity: 0.4m³ – Transport length: 4.78m – Transport width: 2.2m – Transport height: 2.55m

Check out detailed specifications, information and technical data for Menzi M220 excavator manufactured between 2016 - 2020. Get more in-depth insight with Menzi M220 digger specifications. See information, like: Weight: 7.5t – Standard tyres: 500/45-20 – Bucket capacity: 0.4m³ – Transport length: 4.78m – Transport width: 2.2m – Transport height: 2.55m and more.

Walking Excavators Menzi M220

Technical specs - M220 Menzi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.5 t
Standard tyres
500/45-20
Bucket capacity
0.4 m³
Transport length
4.78 m
Transport width
2.2 m
Transport height
2.55 m
Max. Reach horizontal
7.22 m
Dredging depth
4.79 m
Tear-out force
43 kN
Bucket width
0.6 m
Model series
M
Engine manuf.
Deutz
Engine type
TCD2.9 L4
Engine power
55 kW
Displacement
2.9 l
Revolutions at max torque
1600 rpm
Emission level
3b

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard boom and standard bucket

Special equipment

Overload alert
No
Central lubrication
No
Aircondition
No
