C50R-5A Yanmar C50R-5A Specifications & Technical Data (2020—2024)

Weight: 5.29t – Transport length: 4.54m – Transport width: 2.64m – Transport height: 2.675m – Net load: 3.801t – Dump capacity: 3m³

C50R-5A

Years of manufacture: 2020—2024

Data sheet
Valuate & Sell
Spare parts
Transport
News

Technical specs - C50R-5A Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.29 t

Transport length: 4.54 m

Transport width: 2.64 m

Transport height: 2.675 m

Net load: 3.801 t

Dump capacity: 3 m³

Driver protection: FD

Travel speed: 6.2 km/h

Track width: 450 mm

Model series: C

Engine manuf.: Yanmar

Engine type: 4JJ1X

Engine power: 72 kW

More technical details, like: soil pressure, loading height, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: No
Trough liftable: No
Aircondition: No

Download datasheets (PDF)

Yanmar C50R-5A FAQ

When was the Yanmar C50R-5A manufactured?

The Yanmar C50R-5A was manufactured from 2020 to 2024.

How much does the Yanmar C50R-5A weigh?

The Yanmar C50R-5A weighs 5.29 tons.

What are the transport dimensions of the Yanmar C50R-5A tracked dumper?

The Yanmar C50R-5A has a transport length of 4.54 meters, a transport width of 2.64 meters, and a transport height of 2.68 meters.

What is the travel speed of the Yanmar C50R-5A tracked dumper?

The Yanmar C50R-5A tracked dumper has a travel speed of 6.2 km/h.

What is the track width of the Yanmar C50R-5A's undercarriage?

The Yanmar C50R-5A has a track width of 450 mm in its undercarriage.

What is the material handling capacity of the Yanmar C50R-5A tracked dumper?

The Yanmar C50R-5A tracked dumper has a net load capacity of 3.8 tons and a dump capacity of 3 cubic meters.

What operator safety and support features does the Yanmar C50R-5A have?

The Yanmar C50R-5A is equipped with a canopy for driver protection.
