Yanmar C08-A HI TIP Specifications & Technical Data (2023-2026)

Technical specs - C08-A HI TIP Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.67 t

Transport length: 1.926 m

Transport width: 0.81 m

Transport height: 1.35 m

Net load: 0.8 t

Dump capacity: 0.36 m³

Travel speed: 4 km/h

Track width: 180 mm

Soil pressure: 0.52 kg/cm²

Loading height: 0.739 m

Model series: C

Engine manuf.: Yanmar

Engine type: L100V

Engine power: 6.8 kW

Displacement: 0.435 l

Max. torque: 24,3/3100 Nm

No. of cylinders: 1

Emission level: V

More technical details, like: driver protection, turning radius outside, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: Yes
Trough liftable: Yes
Aircondition: No

Download datasheets (PDF)

Yanmar C08-A HI TIP FAQ

When was the Yanmar C08-A HI TIP manufactured?

The Yanmar C08-A HI TIP was first produced in 2024.

How much does the Yanmar C08-A HI TIP weigh?

The Yanmar C08-A HI TIP weighs 0.67 tons.

What are the transport dimensions of the Yanmar C08-A HI TIP tracked dumper?

The Yanmar C08-A HI TIP has a transport length of 1.926 meters, a transport width of 0.81 meters, and a transport height of 1.35 meters.

What is the travel speed of the Yanmar C08-A HI TIP tracked dumper?

The Yanmar C08-A HI TIP tracked dumper has a travel speed of 4 km/h.

What are the undercarriage specifications of the Yanmar C08-A HI TIP tracked dumper?

The Yanmar C08-A HI TIP tracked dumper has a track width of 180 mm and a soil pressure of 0.52 kg/cmu00b2.

What is the material handling capacity of the Yanmar C08-A HI TIP tracked dumper?

The Yanmar C08-A HI TIP tracked dumper has a net load capacity of 0.8 tons, a dump capacity of 0.36 cubic meters, and a loading height of 0.739 meters.

How much is a Yanmar C08-A HI TIP Tracked dumper (2024u20132025) worth?

The residual value of the Yanmar C08-A HI TIP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
