C08-A Diesel Yanmar C08-A Diesel Specifications & Technical Data (2020—2026)
Visit Yanmar live at
Technical specs - C08-A Diesel Yanmar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 0.662 t
- Transport length
- 1.926 m
- Transport width
- 0.81 m
- Transport height
- 1.336 m
- Net load
- 0.8 t
- Dump capacity
- 0.36 m³
- Travel speed
- 4 km/h
- Track width
- 180 mm
- Soil pressure
- 0.52 kg/cm²
- Loading height
- 0.739 m
- Model series
- C
- Engine manuf.
- Yanmar
- Engine type
- LV100
- Engine power
- 6.4 kW
- Displacement
- 0.435 l
- Revolutions at max torque
- 3100 rpm
- Max. torque
- 24.3 Nm
More technical details, like: driver protection, turning radius outside, dimension lxwxh, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Track adjustment
-
No
- Bucket
-
No
- Heated dump body
-
No
- Electric starter
-
No
- Trough liftable
-
No
- Aircondition
-
No
Download datasheets (PDF)
Yanmar C08-A Diesel FAQ
How much does the Yanmar C08-A Diesel weigh?
What are the transport dimensions of the Yanmar C08-A Diesel tracked dumper?
What is the travel speed of the Yanmar C08-A Diesel tracked dumper?
What are the undercarriage specifications of the Yanmar C08-A Diesel tracked dumper?
What is the material handling capacity of the Yanmar C08-A Diesel tracked dumper?
How much is a Yanmar C08-A Diesel Tracked dumper (2023u20132025) worth?
