Wacker Neuson DT 08 PL Specifications & Technical Data (2011-2014)

Technical specs - DT 08 PL Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.6 t

Transport length: 1.79 m

Transport width: 0.8 m

Transport height: 1.27 m

Net load: 0.8 t

Dump capacity: 0.387 m³

Travel speed: 4.2 km/h

Track width: 180 mm

Soil pressure: 0.22 kg/cm²

Loading height: 4.1 m

Model series: DT

Engine manuf.: Kubota

Engine type: Z482

Engine power: 9 kW

Revolutions at max torque: 2600 rpm

More technical details, like: driver protection, turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, undercarriage type, rops...

More technical details, like: driver protection, turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, undercarriage type, rops, fops, engine manufacturer, engine model, rated speed, engine output, torque rated speed, engine torque, fuel, drive, track rollers - each side, track shoe width, service type, width, overall length, track length on ground, ground clearance, skip lip height - untipped, skip lip height - tipped, payload - heaped, payload - struck, payload - water, skip payload, ground bearing pressure, travel speed - maximum, operating weight - unladen, gross weight - standard build are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: Yes
Electric starter: No
Trough liftable: No
Aircondition: No

Download datasheets (PDF)

Wacker Neuson DT 08 PL FAQ

When was the Wacker Neuson DT 08 PL manufactured?

The Wacker Neuson DT 08 PL was manufactured from 2011 to 2014.

How much does the Wacker Neuson DT 08 PL weigh?

The Wacker Neuson DT 08 PL weighs 0.6 tons.

What are the transport dimensions of the Wacker Neuson DT 08 PL?

The Wacker Neuson DT 08 PL has a transport length of 1.79 meters, a transport width of 0.8 meters, and a transport height of 1.27 meters.

What is the travel speed of the Wacker Neuson DT 08 PL?

The Wacker Neuson DT 08 PL has a travel speed of 4.2 km/h.

What are the undercarriage specifications of the Wacker Neuson DT 08 PL?

The Wacker Neuson DT 08 PL has a track width of 180 mm and a soil pressure of 0.22 kg/cmu00b2.

What is the material handling capacity of the Wacker Neuson DT 08 PL?

The Wacker Neuson DT 08 PL has a net load capacity of 0.8 tons, a dump capacity of 0.39 cubic meters, and a loading height of 4.1 meters.

How much is a Wacker Neuson DT 08 PL Tracked dumper (2011u20132014) worth?

The residual value of the Wacker Neuson DT 08 PL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
