MST 300 VD Morooka MST 300 VD Specifications & Technical Data (2014—2026)

Weight: 2.68t – Transport length: 3.15m – Transport width: 1.74m – Transport height: 2.33m – Net load: 2.5t – Dump capacity: 0.88m³

Tracked Dumpers Morooka MST 300 VD

Technical specs - MST 300 VD Morooka

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.68 t
Transport length
3.15 m
Transport width
1.74 m
Transport height
2.33 m
Net load
2.5 t
Dump capacity
0.88 m³
Driver protection
Kb
Travel speed
9 km/h
Track width
350 mm
Loading height
1.19 m
Turning radius outside
1.6 m
Model series
MST
Engine manuf.
Kubota
Engine type
V2203
Engine power
35.4 kW
Revolutions at max torque
2800 rpm
Max. torque
141/1600 Nm
Emission level
Tier 4 i

More technical details, like: soil pressure, dimension lxwxh, displacement, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Buy full specs

Special equipment

Track adjustment
No
Bucket
No
Heated dump body
No
Electric starter
Yes
Trough liftable
Yes
Aircondition
No

Download datasheets (PDF)

Morooka MST 300 VD FAQ

When was the Morooka MST 300 VD manufactured?

The Morooka MST 300 VD was first produced in 2014.

How much does the Morooka MST 300 VD weigh?

The Morooka MST 300 VD weighs 2.68 tons.

What are the transport dimensions of the Morooka MST 300 VD?

The Morooka MST 300 VD has a transport length of 3.15 meters, a transport width of 1.74 meters, and a transport height of 2.33 meters.

What is the travel speed of the Morooka MST 300 VD?

The Morooka MST 300 VD has a travel speed of 9 km/h.

What is the track width of the Morooka MST 300 VD's undercarriage?

The Morooka MST 300 VD has a track width of 350 mm.

What is the outside turning radius of the Morooka MST 300 VD?

The Morooka MST 300 VD has an outside turning radius of 1.6 meters.

What is the material handling capacity of the Morooka MST 300 VD tracked dumper?

The Morooka MST 300 VD has a net load capacity of 2.5 tons, a dump capacity of 0.88 cubic meters, and a loading height of 1.19 meters.

What operator safety feature does the Morooka MST 300 VD have?

The Morooka MST 300 VD has a cabin for driver protection.
