MST 1500 VD Morooka MST 1500 VD Specifications & Technical Data (1998—2010)

Weight: 9.2t – Transport length: 5.3m – Transport width: 2.64m – Transport height: 2.9m – Net load: 6.3t – Dump capacity: 2.73m³

MST 1500 VD

Years of manufacture: 1998—2010

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Reviews
Transport
News

Technical specs - MST 1500 VD Morooka

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 9.2 t

Transport length: 5.3 m

Transport width: 2.64 m

Transport height: 2.9 m

Net load: 6.3 t

Dump capacity: 2.73 m³

Driver protection: Kb

Travel speed: 12 km/h

Track width: 700 mm

Soil pressure: 0.29 kg/cm²

Model series: MST

Engine manuf.: Mitsubishi

Engine type: 6 D 16 TE 1

Engine power: 150 kW

More technical details, like: loading height, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, engine manufacturer, engine model, rated speed, engine output, torque rated speed, engine torque, fuel, drive, track shoe width, height over rops, width, overall length, track length on ground, ground clearance, skip lip height - untipped, skip payload, ground bearing pressure, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: No
Trough liftable: Yes
Aircondition: Yes

Download datasheets (PDF)

MST 1500 VD Morooka Specification for Europe (EN)

Morooka MST 1500 VD FAQ

When was the Morooka MST 1500 VD manufactured?

The Morooka MST 1500 VD was manufactured from 1998 to 2010.

How much does the Morooka MST 1500 VD weigh?

The Morooka MST 1500 VD weighs 9.2 tons.

What are the transport dimensions of the Morooka MST 1500 VD?

The Morooka MST 1500 VD has a transport length of 5.3 meters, a transport width of 2.64 meters, and a transport height of 2.9 meters.

What is the travel speed of the Morooka MST 1500 VD?

The Morooka MST 1500 VD has a travel speed of 12 km/h.

What are the undercarriage specifications of the Morooka MST 1500 VD?

The Morooka MST 1500 VD has a track width of 700 mm and a soil pressure of 0.29 kg/cmu00b2.

What is the material handling capacity of the Morooka MST 1500 VD?

The Morooka MST 1500 VD has a net load capacity of 6.3 tons and a dump capacity of 2.73 cubic meters.

What operator safety and support features does the Morooka MST 1500 VD have?

The Morooka MST 1500 VD provides operator safety with a protective cabin.

How much is a Morooka MST 1500 VD Tracked dumper (1998u20132010) worth?

The residual value of the Morooka MST 1500 VD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
