Hinowa HS400 Specifications & Technical Data (2007-2023)

Technical specs - HS400 Hinowa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.25 t

Transport length: 1.31 m

Transport width: 0.68 m

Transport height: 1.15 m

Net load: 0.45 t

Travel speed: 1.7 km/h

Track width: 150 mm

Model series: HS

Engine manuf.: Honda

Engine type: GX200

Engine power: 4.8 kW

Displacement: 0.196 l

Revolutions at max torque: 3600 rpm

More technical details, like: dump capacity, driver protection, soil pressure, loading height, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline...

More technical details, like: dump capacity, driver protection, soil pressure, loading height, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, fops, engine manufacturer, engine model, rated speed, engine output, fuel, drive, track rollers - each side, track shoe width, width, overall length, track length on ground, skip lip height - tipped, payload - heaped, payload - struck, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: No
Trough liftable: No
Aircondition: No

Download datasheets (PDF)

Hinowa HS400 FAQ

When was the Hinowa HS400 manufactured?

The Hinowa HS400 was manufactured from 2007 to 2023.

How much does the Hinowa HS400 weigh?

The Hinowa HS400 weighs 0.25 tons.

What are the transport dimensions of the Hinowa HS400 tracked dumper?

The Hinowa HS400 tracked dumper has a transport length of 1.31 meters, a transport width of 0.68 meters, and a transport height of 1.15 meters.

What is the travel speed of the Hinowa HS400 tracked dumper?

The Hinowa HS400 tracked dumper has a travel speed of 1.7 km/h.

What is the track width of the Hinowa HS400 tracked dumper?

The Hinowa HS400 has a track width of 150 mm.

What is the material handling capacity of the Hinowa HS400 tracked dumper?

The Hinowa HS400 tracked dumper has a material handling capacity of 0.45 tons.

How much is a Hinowa HS400 Tracked dumper (2007u20132023) worth?

The residual value of the Hinowa HS400 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
