RD 6/6 D HX Gehlmax RD 6/6 D HX Specifications & Technical Data (2007—2012)

Weight: 0.49t – Transport length: 1.07m – Transport width: 0.61m – Transport height: 0.44m – Net load: 0.4t – Dump capacity: 0.29m³

RD 6/6 D HX

Years of manufacture: 2007—2012

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - RD 6/6 D HX Gehlmax

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.49 t

Transport length: 1.07 m

Transport width: 0.61 m

Transport height: 0.44 m

Net load: 0.4 t

Dump capacity: 0.29 m³

Track width: 180 mm

Model series: RD

Engine manuf.: Yanmar

Engine type: Diesel

Engine power: 4.9 kW

More technical details, like: driver protection, travel speed, soil pressure, loading height, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: No
Trough liftable: No
Aircondition: No

Gehlmax RD 6/6 D HX FAQ

When was the Gehlmax RD 6/6 D HX manufactured?

The Gehlmax RD 6/6 D HX was manufactured from 2007 to 2012.

How much does the Gehlmax RD 6/6 D HX weigh?

The Gehlmax RD 6/6 D HX weighs 0.49 tons.

What are the transport dimensions of the Gehlmax RD 6/6 D HX?

The Gehlmax RD 6/6 D HX has a transport length of 1.07 meters, a transport width of 0.61 meters, and a transport height of 0.44 meters.

What is the track width of the Gehlmax RD 6/6 D HX's undercarriage?

The Gehlmax RD 6/6 D HX has a track width of 180 mm.

What is the material handling capacity of the Gehlmax RD 6/6 D HX tracked dumper?

The Gehlmax RD 6/6 D HX tracked dumper has a net load capacity of 0.4 tons and a dump capacity of 0.29 cubic meters.

How much is a Gehlmax RD 6/6 D HX Tracked dumper (2007u20132012) worth?

The residual value of the Gehlmax RD 6/6 D HX depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
