4010T Bergmann 4010T Specifications & Technical Data (2018—2019)
Technical specs - 4010T Bergmann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 13 t
- Transport length
- 6.315 m
- Transport width
- 2.9 m
- Transport height
- 3.022 m
- Net load
- 11 t
- Dump capacity
- 6.6 m³
- Driver protection
- Kb
- Travel speed
- 15 km/h
- Track width
- 750 mm
- Soil pressure
- 0.5 kg/cm²
- Loading height
- 2.175 m
- Model series
- 4000
- Engine manuf.
- Cummins
- Engine type
- QSB6.7
- Engine power
- 180 kW
- Revolutions at max torque
- 2300 rpm
- Emission level
- Tier 4 f
More technical details, like: turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Track adjustment
-
No
- Bucket
-
No
- Heated dump body
-
No
- Electric starter
-
No
- Trough liftable
-
No
- Aircondition
-
No
