4010R Bergmann 4010R Specifications & Technical Data (2016—2019)

Weight: 14.85t – Transport length: 6.315m – Transport width: 2.9m – Transport height: 3.02m – Net load: 10t – Dump capacity: 6.6m³

4010R

Years of manufacture: 2016—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 4010R Bergmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 14.85 t

Transport length: 6.315 m

Transport width: 2.9 m

Transport height: 3.02 m

Net load: 10 t

Dump capacity: 6.6 m³

Driver protection: Kb

Travel speed: 15 km/h

Track width: 750 mm

Soil pressure: 0.5 kg/cm²

Loading height: 2.175 m

Model series: 4000

Engine manuf.: Cummins

Engine type: QSB6.7

Engine power: 180 kW

Revolutions at max torque: 2300 rpm

Emission level: Tier 4 f

More technical details, like: turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, emission rating, engine output, fuel, drive, height over rops, width, overall length, ground clearance, skip lip height - tipped, payload - heaped, payload - water, skip payload, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Track adjustment: No
Bucket: No
Heated dump body: No
Electric starter: No
Trough liftable: No
Aircondition: No

Download datasheets (PDF)

Bergmann 4010R FAQ

When was the Bergmann 4010R manufactured?

The Bergmann 4010R was manufactured from 2016 to 2019.

How much does the Bergmann 4010R weigh?

The Bergmann 4010R weighs 14.85 tons.

What are the transport dimensions of the Bergmann 4010R?

The Bergmann 4010R has a transport length of 6.32 meters, a transport width of 2.9 meters, and a transport height of 3.02 meters.

What is the travel speed of the Bergmann 4010R tracked dumper?

The Bergmann 4010R tracked dumper has a travel speed of 15 km/h.

What are the undercarriage specifications of the Bergmann 4010R?

The Bergmann 4010R has a track width of 750 mm and a soil pressure of 0.5 kg/cmu00b2.

What is the material handling capacity of the Bergmann 4010R tracked dumper?

The Bergmann 4010R tracked dumper has a net load capacity of 10 tons and a dump capacity of 6.6 cubic meters.

What operator safety and support features does the Bergmann 4010R have?

The Bergmann 4010R provides operator safety with a driver protection cabin.

How much is a Bergmann 4010R Tracked dumper (2016u20132019) worth?

The residual value of the Bergmann 4010R depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
