Terex CR562 Specifications & Technical Data (2008-2023)

Technical specs - CR562 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 19.239 t

Transport length: 6.35 m

Transport width: 3.15 m

Transport height: 2.794 m

Standard width: 3.05 m

Max. width: 9.1 m

Drive: DE

Bunker capacity: 7.56 m³

Operating speed: 41 m/min

Type of screed: V

Engine manuf.: Cummins

Engine type: QSB6.7

Engine power: 194 kW

Revolutions at max torque: 2200 rpm

More technical details, like: hydr. extension from, hydr. extension up to, soil pressure, model series, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Vibration: No
High compaction: No
Spray unit: No
Tamper: No

Download datasheets (PDF)

CR562 Terex Specification for North America (EN)

Terex CR562 FAQ

When was the Terex CR562 manufactured?

The Terex CR562 was manufactured from 2008 to 2023.

How much does the Terex CR562 weigh?

The Terex CR562 weighs 19.24 tons.

What are the transport dimensions of the Terex CR562?

The Terex CR562 has a transport length of 6.35 meters, a transport width of 3.15 meters, and a transport height of 2.79 meters.

What is the operating speed of the Terex CR562 tracked asphalt paver?

The Terex CR562 has an operating speed of 41 meters per minute.

What type of drive system does the Terex CR562 tracked asphalt paver use?

The Terex CR562 uses a diesel electric drive system for its undercarriage.

What are the paving performance specifications of the Terex CR562 tracked asphalt paver?

The Terex CR562 features a vibratory screed, a standard paving width of 3.05 meters, a maximum paving width of 9.1 meters, and an operating speed of 41 meters per minute.

How much is a Terex CR562 Tracked Asphalt Paver (2008u20132023) worth?

The residual value of the Terex CR562 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
