MF2500CL Dynapac MF2500CL Specifications & Technical Data (2021—2026)

Weight: 22t – Transport length: 13.5m – Transport width: 2.55m – Transport height: 3.1m – Standard width: 2.55m – Max. width: 3.35m

Tracked Asphalt Pavers Dynapac MF2500CL

Visit Dynapac live at

Technical specs - MF2500CL Dynapac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22 t
Transport length
13.5 m
Transport width
2.55 m
Transport height
3.1 m
Standard width
2.55 m
Max. width
3.35 m
Hydr. extension from
1.9 m
Hydr. extension up to
4.4 m
Bunker capacity
6 m³
Operating speed
25 m/min
Model series
MF

More technical details, like: drive, soil pressure, type of screed, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with operator cabin roof, std. beam and screed plate heating Prices and weights refer to the std. width (most demanded/sold width), excl. hydraulic or manual extention

Special equipment

Diesel particulate filter
No
Bilateral levelling automatic
No
Vibration
No
High compaction
No
Spray unit
No
Tamper
No

Download datasheets (PDF)

Dynapac MF2500CL FAQ

When was the Dynapac MF2500CL manufactured?

The Dynapac MF2500CL was first produced in 2021.

How much does the Dynapac MF2500CL weigh?

The Dynapac MF2500CL weighs 22 tons.

What are the transport dimensions of the Dynapac MF2500CL?

The Dynapac MF2500CL has a transport length of 13.5 meters, a transport width of 2.55 meters, and a transport height of 3.1 meters.

What is the operating speed of the Dynapac MF2500CL asphalt paver?

The Dynapac MF2500CL has an operating speed of 25 meters per minute.

What are the paving performance specifications of the Dynapac MF2500CL tracked asphalt paver?

The Dynapac MF2500CL has a standard paving width of 2.55 meters, a maximum width of 3.35 meters, hydraulic extensions ranging from 1.9 to 4.4 meters, an operating speed of 25 meters per minute, and a bunker capacity of 6 cubic meters.

How much is a Dynapac MF2500CL Tracked Asphalt Paver (2021u20132025) worth?

The residual value of the Dynapac MF2500CL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
