S24C Terex S24C Specifications & Technical Data (1989—2023)

Weight: 45.884t – Standard tyres: 37.5-33 (36PR) E3 – Dump capacity: 26m³ – Transport length: 14.78m – Transport width: 3.45m – Transport height: 3.94m

Scrapers Terex S24C

Technical specs - S24C Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
45.884 t
Standard tyres
37.5-33 (36PR) E3
Dump capacity
26 m³
Transport length
14.78 m
Transport width
3.45 m
Transport height
3.94 m
Travel speed
55 km/h
Turning radius outside
13.7 m
Net load
37 t
Engine manuf.
Detroit Diesel
Engine type
8V-71T
Engine power
209 kW
Displacement
9.3 l
Revolutions at max torque
1200 rpm
Max. torque
1091 Nm
No. of cylinders
8
Cylinder bore x stroke
108x127 mm

More technical details, like: power of 2nd engine, cutting width, max. total weight, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Aircondition
No
