Terex S-35E
- Weight:
- 44.86 t
- Standard tyres:
- 37.5x33-36 PR. E3
- Dump capacity:
- 26.8 m³
- Transport length:
- 14.326 m
S-35E Terex S-35E Specifications & Technical Data (1975—1980)
Technical specs - S-35E Terex
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 44.86 t
- Standard tyres
- 37.5x33-36 PR. E3
- Dump capacity
- 26.8 m³
- Transport length
- 14.326 m
- Transport width
- 3.454 m
- Transport height
- 4.013 m
- Net load
- 38.102 t
- Engine manuf.
- Detroit Diesel
- Engine type
- 12V-71T
- Engine power
- 341 kW
- Displacement
- 13.9 l
- Revolutions at max torque
- 1400 rpm
- Max. torque
- 1871 Nm
- No. of cylinders
- 12
- Cylinder bore x stroke
- 108x127 mm
More technical details, like: power of 2nd engine, cutting width, max. total weight, travel speed, turning radius outside, model series, dimension lxwxh, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Aircondition
-
No
