862B John Deere Construction 862B Specifications & Technical Data (1986—2021)

Weight: 22.312t – Dump capacity: 12.23m³ – max. total weight: 40.46t – Travel speed: 45km/h – Turning radius outside: 9.89m – Net load: 18.14t

Technical specs - 862B John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.312 t
Dump capacity
12.23 m³
max. total weight
40.46 t
Travel speed
45 km/h
Turning radius outside
9.89 m
Net load
18.14 t
Model series
B
Engine manuf.
John Deere
Engine type
6619A
Engine power
198 kW
Displacement
10.145 l
Max. torque
1169 Nm
No. of cylinders
6

More technical details, like: standard tyres, power of 2nd engine, cutting width, transport length, transport width, transport height, dimension lxwxh, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Aircondition
No
