637D Caterpillar 637D Specifications & Technical Data (1979—1991)

Weight: 48.23t – Standard tyres: 33.25-35 38PR – Power of 2nd engine: 187kW – Dump capacity: 23.7m³ – Cutting width: 3490mm – max. total weight: 82.25t

Scrapers Caterpillar 637D

Technical specs - 637D Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
48.23 t
Standard tyres
33.25-35 38PR
Power of 2nd engine
187 kW
Dump capacity
23.7 m³
Cutting width
3490 mm
max. total weight
82.25 t
Transport length
14.83 m
Transport width
3.96 m
Transport height
4.17 m
Travel speed
48.3 km/h
Turning radius outside
12.2 m
Net load
34.02 t
Engine manuf.
Caterpillar
Engine type
3408
Engine power
335 kW
Displacement
18 l
Revolutions at max torque
2000 rpm

More technical details, like: model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Aircondition
No
