Technical specs - ARR 1585 St V Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.48 t

Transport length: 1.87 m

Transport width: 0.85 m

Transport height: 1.2 m

Vibration: d

Frequency: 30 Hz

Roller width: 0.85 m

Rollers Ø: 0.83 m

Amplitude: 2.4 mm

Statical line load: 51 kg/cm

Model series: ARR

Engine manuf.: Hatz

Engine type: 2 D 40

Engine power: 13.4 kW

Revolutions at max torque: 2600 rpm

Emission level: EU V

More technical details, like: drive, travel speed, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model

Special equipment

Diesel particulate filter: No
Remote control: Yes

Ammann ARR 1585 St V FAQ

When was the Ammann ARR 1585 St V manufactured?

The Ammann ARR 1585 St V was first produced in 2020.

How much does the Ammann ARR 1585 St V weigh?

The Ammann ARR 1585 St V weighs 1.48 tons.

What are the transport dimensions of the Ammann ARR 1585 St V?

The Ammann ARR 1585 St V has a transport length of 1.87 meters, a transport width of 0.85 meters, and a transport height of 1.2 meters.

What are the compaction capabilities of the Ammann ARR 1585 St V vibration trench roller?

The Ammann ARR 1585 St V features a double vibration system with a frequency of 30 Hz, an amplitude of 2.4 mm, and a statical line load of 51 kg/cm.

What are the roller specifications of the Ammann ARR 1585 St V vibration trench roller?

The Ammann ARR 1585 St V has rollers that are 0.85 meters wide with a diameter of 0.83 meters.
