Technical specs - ARR 1575 T4f Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.45 t
- Transport length
- 2.23 m
- Transport width
- 0.85 m
- Transport height
- 1.2 m
- Vibration
- d
- Frequency
- 40 Hz
- Roller width
- 0.85 m
- Rollers Ø
- 0.53 m
- Amplitude
- 1 mm
- Statical line load
- 44 kg/cm
- Model series
- ARR
- Engine manuf.
- Yanmar
- Engine type
- 3TNV80F
- Engine power
- 14.6 kW
- Displacement
- 1.267 l
- Revolutions at max torque
- 2400 rpm
- Max. torque
- 64.7/1800 Nm
- No. of cylinders
- 4
- Emission level
- V
More technical details, like: drive, travel speed, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model
Special equipment
- Diesel particulate filter
-
No
- Remote control
-
No
