ARR 1575 St V Ammann ARR 1575 St V Specifications & Technical Data (2020—2026)

Weight: 1.45t – Transport length: 2.227m – Transport width: 0.85m – Transport height: 1.2m – Vibration: d – Frequency: 40Hz

Rollers Vibration Trench Rollers Ammann ARR 1575 St V
Rollers Vibration Trench Rollers Ammann ARR 1575 St V
Rollers Vibration Trench Rollers Ammann ARR 1575 St V
Rollers Vibration Trench Rollers Ammann ARR 1575 St V
Rollers Vibration Trench Rollers Ammann ARR 1575 St V
Rollers Vibration Trench Rollers Ammann ARR 1575 St V
Rollers Vibration Trench Rollers Ammann ARR 1575 St V
Rollers Vibration Trench Rollers Ammann ARR 1575 St V

Technical specs - ARR 1575 St V Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.45 t
Transport length
2.227 m
Transport width
0.85 m
Transport height
1.2 m
Vibration
d
Frequency
40 Hz
Roller width
0.85 m
Rollers Ø
0.53 m
Amplitude
1 mm
Statical line load
44 kg/cm
Model series
ARR
Engine manuf.
Yanmar
Engine type
3TNV80F
Engine power
14.6 kW
Revolutions at max torque
1800 rpm
Emission level
EU V

More technical details, like: drive, travel speed, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model

Special equipment

Diesel particulate filter
No
Remote control
Yes

Download datasheets (PDF)

Ammann ARR 1575 St V FAQ

When was the Ammann ARR 1575 St V manufactured?

The Ammann ARR 1575 St V was first produced in 2020.

How much does the Ammann ARR 1575 St V weigh?

The Ammann ARR 1575 St V weighs 1.45 tons.

What are the transport dimensions of the Ammann ARR 1575 St V vibration trench roller?

The Ammann ARR 1575 St V has a transport length of 2.227 meters, a transport width of 0.85 meters, and a transport height of 1.2 meters.

What are the compaction capabilities of the Ammann ARR 1575 St V vibration trench roller?

The Ammann ARR 1575 St V features a double vibration system, operates at a frequency of 40 Hz with an amplitude of 1 mm, and has a statical line load of 44 kg/cm.

What are the roller specifications of the Ammann ARR 1575 St V vibration trench roller?

The Ammann ARR 1575 St V has rollers that are 0.85 meters wide with a diameter of 0.53 meters.
