VM 651 PD JCB-Vibromax VM 651 PD Specifications & Technical Data (2008—2009)

Weight: 6.5t – Transport length: 4.6m – Transport width: 2.3m – Transport height: 1.73m – Rollers Ø: 1.5m – Roller width: 2.1m

Rollers Trailed Rollers JCB-Vibromax VM 651 PD

Technical specs - VM 651 PD JCB-Vibromax

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.5 t
Transport length
4.6 m
Transport width
2.3 m
Transport height
1.73 m
Rollers Ø
1.5 m
Roller width
2.1 m
Frequency
40 Hz
Statical line load
30 kg/cm
Model series
VM
Engine manuf.
Deutz
Engine type
F3L914
Engine power
42 kW
Displacement
1.5 l
Revolutions at max torque
2500 rpm

More technical details, like: vibration, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with hitch

Special equipment

Sheep foot
No

Download datasheets (PDF)

JCB-Vibromax VM 651 PD FAQ

When was the JCB-Vibromax VM 651 PD manufactured?

The JCB-Vibromax VM 651 PD was manufactured from 2008 to 2009.

How much does the JCB-Vibromax VM 651 PD weigh?

The JCB-Vibromax VM 651 PD weighs 6.5 tons.

What are the transport dimensions of the JCB-Vibromax VM 651 PD?

The JCB-Vibromax VM 651 PD has a transport length of 4.6 meters, a transport width of 2.3 meters, and a transport height of 1.73 meters.

What are the compaction capabilities of the JCB-Vibromax VM 651 PD?

The JCB-Vibromax VM 651 PD operates at a frequency of 40 Hz and has a statical line load of 30 kg/cm.

What are the roller specifications of the JCB-Vibromax VM 651 PD?

The JCB-Vibromax VM 651 PD has rollers with a width of 2.1 meters and a diameter of 1.5 meters.

How much is a JCB-Vibromax VM 651 PD Trailed Roller (2008u20132009) worth?

The residual value of the JCB-Vibromax VM 651 PD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
