RD28-120 Wacker Neuson RD28-120 Specifications & Technical Data (2021—2026)

Weight: 2.695t – Transport length: 2.53m – Transport width: 1.31m – Transport height: 2.378m – Vibration: e – Drive: A

Rollers Tandem Vibration Rollers Wacker Neuson RD28-120

Visit Wacker Neuson live at

Technical specs - RD28-120 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.695 t
Transport length
2.53 m
Transport width
1.31 m
Transport height
2.378 m
Vibration
e
Drive
A
Steering
KL
Travel speed
10.6 km/h
Frequency
65 Hz
Roller width
1.25 m
Rollers Ø
0.72 m
Turning radius outside
2.37 m
Centrifugal force
52 kN
Model series
RD
Engine manuf.
Kubota
Engine type
D1803-CR
Engine power
24 kW
Displacement
1.826 l
No. of cylinders
3
Emission level
V/Tier 4

More technical details, like: statical line load, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
Yes
Oscillation
Yes
Compression control
No
Aircondition
No

Download datasheets (PDF)

Wacker Neuson RD28-120 FAQ

When was the Wacker Neuson RD28-120 manufactured?

The Wacker Neuson RD28-120 was first produced in 2021.

How much does the Wacker Neuson RD28-120 weigh?

The Wacker Neuson RD28-120 weighs 2.7 tons.

What are the transport dimensions of the Wacker Neuson RD28-120?

The Wacker Neuson RD28-120 has a transport length of 2.53 meters, a transport width of 1.31 meters, and a transport height of 2.38 meters.

What is the travel speed of the Wacker Neuson RD28-120?

The Wacker Neuson RD28-120 has a travel speed of 10.6 km/h.

What type of drive does the Wacker Neuson RD28-120 have in its undercarriage?

The Wacker Neuson RD28-120 has an all-wheel drive undercarriage.

What are the maneuverability specifications of the Wacker Neuson RD28-120 tandem vibration roller?

The Wacker Neuson RD28-120 has an articulated-frame steering system and an outside turning radius of 2.37 meters.

What are the compaction capabilities of the Wacker Neuson RD28-120 tandem vibration roller?

The Wacker Neuson RD28-120 features a single vibration system, operates at a frequency of 65 Hz, and generates a centrifugal force of 52 kN.

What are the roller specifications of the Wacker Neuson RD28-120 tandem vibration roller?

The Wacker Neuson RD28-120 has rollers that are 1.25 meters wide with a diameter of 0.72 meters.

How much is a Wacker Neuson RD28-120 Tandem Vibration Roller (2021u20132025) worth?

The residual value of the Wacker Neuson RD28-120 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Wacker Neuson RD28-120 overview

Drums / Wheels

Perfect view, perfect performance

Due to the specially tapered design of the articulated tandem-axle rollers, the operator always has the drum edges, the machine environment and the job site in view. This ensures ideal compaction results. The ergonomic operator's platform, the vibration-reduced driver's cabin and the 3-point articulated joint provide for maximum driving comfort. In crab steering mode, you can also easily compact in narrow edge areas or along curbs.Optimal visual conditions due to the slim designEdge pressing and cutting equipment for a clean edge of the paths (option)Safe ROPS (Roll Over Protective Structure) that can be folded back for transportInstalled articulated pendulum joint ensures for uniform compaction, a high level of maneuverability and a high level of driving stabilityThree model versions: Tandem-axle roller with 2 vibrating drums, combination roller or tandem-axle roller with oscillating drum
