RD 16-100 Wacker Neuson RD 16-100 Specifications & Technical Data (2009—2014)

Weight: 1.52t – Transport length: 1.95m – Transport width: 1.102m – Transport height: 2.545m – Vibration: e/d – Drive: A

Rollers Tandem Vibration Rollers Wacker Neuson RD 16-100
Rollers Tandem Vibration Rollers Wacker Neuson RD 16-100
Rollers Tandem Vibration Rollers Wacker Neuson RD 16-100
Rollers Tandem Vibration Rollers Wacker Neuson RD 16-100
Rollers Tandem Vibration Rollers Wacker Neuson RD 16-100
Rollers Tandem Vibration Rollers Wacker Neuson RD 16-100

Visit Wacker Neuson live at

Technical specs - RD 16-100 Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.52 t
Transport length
1.95 m
Transport width
1.102 m
Transport height
2.545 m
Vibration
e/d
Drive
A
Steering
KL
Travel speed
9.3 km/h
Frequency
70 Hz
Roller width
1 m
Rollers Ø
0.56 m
Turning radius outside
2 m
Statical line load
7.9 kg/cm
Model series
RD
Engine manuf.
Lombardini
Engine type
LDW 1003
Engine power
20 kW
Dimension lxwxh
412x513x515.5 mm
Displacement
1.028 l
Revolutions at max torque
3600 rpm
Cylinder bore x stroke
75 mm
Emission level
97/68/CE Step 2

More technical details, like: centrifugal force, max. torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Oscillation
No
Compression control
No
Aircondition
No

Download datasheets (PDF)

Wacker Neuson RD 16-100 FAQ

When was the Wacker Neuson RD 16-100 manufactured?

The Wacker Neuson RD 16-100 was manufactured from 2009 to 2014.

How much does the Wacker Neuson RD 16-100 weigh?

The Wacker Neuson RD 16-100 weighs 1.52 tons.

What are the transport dimensions of the Wacker Neuson RD 16-100?

The Wacker Neuson RD 16-100 has a transport length of 1.95 meters, a transport width of 1.1 meters, and a transport height of 2.55 meters.

What is the travel speed of the Wacker Neuson RD 16-100?

The Wacker Neuson RD 16-100 has a travel speed of 9.3 km/h.

What type of drive does the undercarriage of the Wacker Neuson RD 16-100 have?

The undercarriage of the Wacker Neuson RD 16-100 features an all-wheel drive system.

What are the maneuverability specifications of the Wacker Neuson RD 16-100 tandem vibration roller?

The Wacker Neuson RD 16-100 features articulated-frame steering and has an outside turning radius of 2 meters.

What are the compaction capabilities of the Wacker Neuson RD 16-100?

The Wacker Neuson RD 16-100 features double and single vibration modes, operates at a frequency of 70 Hz, and has a statical line load of 7.9 kg/cm.

What are the roller specifications of the Wacker Neuson RD 16-100?

The Wacker Neuson RD 16-100 has rollers that are 1 meter wide with a diameter of 0.56 meters.

How much is a Wacker Neuson RD 16-100 Tandem Vibration Roller (2009u20132014) worth?

The residual value of the Wacker Neuson RD 16-100 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
