Volvo DD95 Specifications & Technical Data (2008-2016)

Technical specs - DD95 Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 9.4 t

Transport length: 4.22 m

Transport width: 1.81 m

Transport height: 3 m

Vibration: d

Drive: A

Steering: SL

Frequency: 50 Hz

Roller width: 1.68 m

Rollers Ø: 1.22 m

Model series: DD

Engine manuf.: Deutz

Engine type: BF4M2011

Engine power: 60 kW

More technical details, like: travel speed, turning radius outside, statical line load, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Volvo DD95 FAQ

When was the Volvo DD95 manufactured?

The Volvo DD95 was manufactured from 2008 to 2016.

How much does the Volvo DD95 weigh?

The Volvo DD95 weighs 9.4 tons.

What are the transport dimensions of the Volvo DD95 tandem vibration roller?

The Volvo DD95 has a transport length of 4.22 meters, a transport width of 1.81 meters, and a transport height of 3 meters.

What is the drive type of the Volvo DD95's undercarriage?

The Volvo DD95 has an all-wheel drive.

What type of steering system does the Volvo DD95 use for maneuverability?

The Volvo DD95 uses a center pivot plate steering system for maneuverability.

What is the vibration type and frequency of the Volvo DD95 tandem vibration roller?

The Volvo DD95 tandem vibration roller has a double vibration system and operates at a frequency of 50 Hz.

What are the roller specifications of the Volvo DD95 tandem vibration roller?

The Volvo DD95 tandem vibration roller has a roller width of 1.68 meters and roller diameters of 1.22 meters.

How much is a Volvo DD95 Tandem Vibration Roller (2008u20132016) worth?

The residual value of the Volvo DD95 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Volvo DD95 overview

Engine

Economical and low noise working conditions

The tandem vibrating roller is powered by the 60 kW diesel engine. The engine control system optimizes the power utilization for low noise, emissions and fuel consumption.

Vibratory System

Volvo DD85 and Volvo DD95

The Volvo DD85 and DD95 tandem vibrating rollers are specialists for asphalt compaction in construction of everything from small roads to highways. With the easy to operate electronic control system, they can be maneuvered with exceptional sensitivity and precision. Drivers benefit from stable straight ahead travel, uniform cornering and the shorter offset operating mode. Thanks to the high amplitude, large layer thicknesses can be compacted with excellent result.

Visibility

360° visibility

The allround visibility provides a good view of the drum outer edges even when travelling in offset mode.

Water Spray System

Designed for easy maintenance

With easy access to everyday maintenance points like engine filling nozzle, tank nozzle and oil drain tube. The controls for the travel drive, travel drive and the electric circuits are easily accessible in the cab.

Designed for a long service life

The vibration, centrifugal force and flyweights are all lubricated with oil. On the hydraulic travel drive, a drive motor with a large four-point bearing ensures a long service life.

Steering / Brakes

Rigid Frame Steering for Best Results

The rigid frame steering enables the operator to work in the crab mode. This means careful operation along kerbs, precise use of the edge cellular and edge compactor as well as increased area coverage.
