TV 1300 Terex TV 1300 Specifications & Technical Data (2010—2017)

Weight: 3.43t – Transport length: 2.37m – Transport width: 1.37m – Transport height: 1.94m – Vibration: d – Steering: KL

Rollers Tandem Vibration Rollers Terex TV 1300
Rollers Tandem Vibration Rollers Terex TV 1300
Rollers Tandem Vibration Rollers Terex TV 1300
Rollers Tandem Vibration Rollers Terex TV 1300

Technical specs - TV 1300 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
3.43 t
Transport length
2.37 m
Transport width
1.37 m
Transport height
1.94 m
Vibration
d
Steering
KL
Travel speed
10 km/h
Frequency
56 Hz
Roller width
1.3 m
Rollers Ø
0.7 m
Turning radius outside
2.48 m
Statical line load
13.21 kg/cm
Model series
TV
Engine manuf.
Kubota
Engine type
D2203M
Engine power
32.4 kW
Displacement
2.197 l
Revolutions at max torque
2800 rpm

More technical details, like: drive, centrifugal force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Oscillation
No
Compression control
No
Aircondition
No

Download datasheets (PDF)

Terex TV 1300 FAQ

When was the Terex TV 1300 manufactured?

The Terex TV 1300 was manufactured from 2010 to 2017.

How much does the Terex TV 1300 weigh?

The Terex TV 1300 weighs 3.43 tons.

What are the transport dimensions of the Terex TV 1300 tandem vibration roller?

The Terex TV 1300 has a transport length of 2.37 meters, a transport width of 1.37 meters, and a transport height of 1.94 meters.

What is the travel speed of the Terex TV 1300 tandem vibration roller?

The Terex TV 1300 has a travel speed of 10 km/h.

What are the maneuverability specifications of the Terex TV 1300 tandem vibration roller?

The Terex TV 1300 features articulated-frame steering and has an outside turning radius of 2.48 meters.

What are the compaction capabilities of the Terex TV 1300 tandem vibration roller?

The Terex TV 1300 features a double vibration system operating at a frequency of 56 Hz and has a statical line load of 13.21 kg/cm.

What are the roller specifications of the Terex TV 1300 tandem vibration roller?

The Terex TV 1300 has rollers that are 1.3 meters wide with a diameter of 0.7 meters.

How much is a Terex TV 1300 Tandem Vibration Roller (2010u20132017) worth?

The residual value of the Terex TV 1300 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Terex TV 1300 overview

Operator’s Station

Features

Powerful and reliable water cooled Kubota engines. Superb service access and easy to service components. High quality heavy duty design - rental tough. Heavy duty vibration system with high centrifugal force, frequency and static linear load reduces the number of passes required. Unique side control arm for increased operator leg room and comfort. Unique 6 in 1 control lever for simple and easy operation of all functions. Twin drum vibration or rear drum vibration only can be selected via a simple lever. Lockable instrument panel, water tank filler flap and bonnet to reduce theft and vandalism.
