SRD14-C6 Shantui SRD14-C6 Specifications & Technical Data (2025—2026)

Weight: 14t – Transport length: 5.1m – Transport width: 2.3m – Transport height: 3.26m – Travel speed: 12km/h – Frequency: 50Hz

Rollers Tandem Vibration Rollers Shantui SRD14-C6

Technical specs - SRD14-C6 Shantui

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
14 t
Transport length
5.1 m
Transport width
2.3 m
Transport height
3.26 m
Travel speed
12 km/h
Frequency
50 Hz
Turning radius outside
6.7 m
Centrifugal force
140 kN
Engine manuf.
Cummins
Engine type
N/a
Engine power
119 kW
Emission level
Stage IIIA

More technical details, like: vibration, drive, steering, roller width, rollers Ø, statical line load, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Oscillation
No
Compression control
No
Aircondition
No
