Shantui SRD03 Specifications & Technical Data (2020-2025)

Q: When was the Shantui SRD03 manufactured?

The Shantui SRD03 was first produced in 2020.

Q: How much does the Shantui SRD03 weigh?

The Shantui SRD03 weighs 2.9 tons.

Q: What are the transport dimensions of the Shantui SRD03 tandem vibration roller?

The Shantui SRD03 has transport dimensions of 2.8 meters in length, 1.45 meters in width, and 2.1 meters in height.

Q: What is the vibration frequency of the Shantui SRD03's compaction system?

The compaction system of the Shantui SRD03 operates at a vibration frequency of 60 Hz.

Q: What is the roller width of the Shantui SRD03 tandem vibration roller?

The Shantui SRD03 tandem vibration roller has a roller width of 1.2 meters.

Q: How much is a Shantui SRD03 Tandem Vibration Roller (2020u20132025) worth?

The residual value of the Shantui SRD03 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Technical specs - SRD03 Shantui

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.9 t

Transport length: 2.8 m

Transport width: 1.45 m

Transport height: 2.1 m

Frequency: 60 Hz

Roller width: 1.2 m

Model series: <14T

Engine manuf.: Yanmar

Engine type: 388

Engine power: 26.9 kW

More technical details, like: vibration, drive, steering, travel speed, rollers Ø, turning radius outside, statical line load, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: vibration, drive, steering, travel speed, rollers Ø, turning radius outside, statical line load, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No
