SW774 Sakai SW774 Specifications & Technical Data (2026—2026)

Weight: 10.475t – Transport length: 4.85m – Transport width: 1.87m – Transport height: 3.225m – Vibration: d – Drive: A

Technical specs - SW774 Sakai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
10.475 t
Transport length
4.85 m
Transport width
1.87 m
Transport height
3.225 m
Vibration
d
Drive
A
Travel speed
12 km/h
Frequency
66.7 Hz
Roller width
1.68 m
Rollers Ø
1.25 m
Turning radius outside
6.3 m
Centrifugal force
103 kN
Model series
SW
Engine manuf.
Kubota
Engine type
V3800-CR-TI-EV03
Engine power
81.8 kW
Displacement
3.8 l
No. of cylinders
4
Emission level
Tier 4

More technical details, like: steering, statical line load, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Oscillation
Yes
Compression control
No
Aircondition
No
