Sakai HS67ST Specifications & Technical Data (2017-2024)

Rate this machine now!

Weight: 0.75t – Transport length: 2.475m – Transport width: 0.685m – Transport height: 1.825m – Vibration: d – Drive: A

Technical specs - HS67ST Sakai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 0.75 t
  • Transport length 2.475 m
  • Transport width 0.685 m
  • Transport height 1.825 m
  • Vibration d
  • Drive A
  • Travel speed 3.5 km/h
  • Frequency 55 Hz
  • Roller width 0.635 m
  • Centrifugal force 11.8 kN
  • Model series HS67S
  • Engine manuf. Kubota
  • Engine type E75-E3-NB3
  • Engine power 4.6 kW
  • Revolutions at max torque 2500 rpm
  • No. of cylinders 1
  • Emission level non EPA

More technical details, like: average fuel consumption, fuel consumption range (min - max), steering, rollers Ø, turning radius outside, statical line load, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

  • Diesel particulate filter
  • Oscillation
  • Compression control
  • Aircondition
