VMT260-100 JCB-Vibromax VMT260-100 Specifications & Technical Data (2008—2014)

Model rating
7,75 / 10

Weight: 2.6t – Transport length: 1.49m – Transport width: 1.08m – Transport height: 2.48m – Vibration: e – Travel speed: 11km/h

Rollers Tandem Vibration Rollers JCB-Vibromax VMT260-100

Technical specs - VMT260-100 JCB-Vibromax

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.6 t
Transport length
1.49 m
Transport width
1.08 m
Transport height
2.48 m
Vibration
e
Travel speed
11 km/h
Frequency
50 Hz
Roller width
1 m
Rollers Ø
0.7 m
Turning radius outside
2.2 m
Statical line load
13 kg/cm
Model series
VMT
Engine manuf.
Kubota
Engine type
D1503
Engine power
23.5 kW
Displacement
1.647 l

More technical details, like: drive, steering, centrifugal force, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Oscillation
No
Compression control
No
Aircondition
No

Download datasheets (PDF)

JCB-Vibromax VMT260-100 FAQ

When was the JCB-Vibromax VMT260-100 manufactured?

The JCB-Vibromax VMT260-100 was manufactured from 2008 to 2014.

How much does the JCB-Vibromax VMT260-100 weigh?

The JCB-Vibromax VMT260-100 weighs 2.6 tons.

What are the transport dimensions of the JCB-Vibromax VMT260-100 tandem vibration roller?

The JCB-Vibromax VMT260-100 has a transport length of 1.49 meters, a transport width of 1.08 meters, and a transport height of 2.48 meters.

What is the travel speed of the JCB-Vibromax VMT260-100?

The JCB-Vibromax VMT260-100 has a travel speed of 11 km/h.

What is the turning radius of the JCB-Vibromax VMT260-100 tandem vibration roller?

The JCB-Vibromax VMT260-100 has an outside turning radius of 2.2 meters.

What are the compaction capabilities of the JCB-Vibromax VMT260-100?

The JCB-Vibromax VMT260-100 features a single vibration system operating at a frequency of 50 Hz and has a statical line load of 13 kg/cm.

What are the roller specifications of the JCB-Vibromax VMT260-100?

The JCB-Vibromax VMT260-100 has rollers that are 1 meter wide with a diameter of 0.7 meters.

How much is a JCB-Vibromax VMT260-100 Tandem Vibration Roller (2008u20132014) worth?

The residual value of the JCB-Vibromax VMT260-100 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

JCB-Vibromax VMT260-100 overview

Engine

Drivers Stand/Instruments

Fuel, battery charging current, sprinkler system, parking brake, hour meter, engine oil pressure, air filter condition, hydraulic oil level and temperature, water level indicator.


Steering / Brakes

Propulsion

Hydrostatic with variable displacement pump and fixed displacement motors with direct drive to both drums = double drum drive.
