Hamm HD+ 70i VO Specifications & Technical Data (2019-2026)

Technical specs - HD+ 70i VO Hamm

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.43 t

Transport length: 4.48 m

Transport width: 1.79 m

Transport height: 2.89 m

Vibration: d

Drive: A

Steering: KL

Frequency: 58 Hz

Roller width: 1.5 m

Rollers Ø: 1.14 m

Turning radius outside: 4.23 m

Statical line load: 25 kg/cm

Centrifugal force: 84 kN

Model series: HD+

Engine manuf.: Deutz

Engine type: TCD 2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 4

Emission level: V

More technical details, like: travel speed, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Hamm HD+ 70i VO FAQ

When was the Hamm HD+ 70i VO manufactured?

The Hamm HD+ 70i VO was first produced in 2019.

How much does the Hamm HD+ 70i VO weigh?

The Hamm HD+ 70i VO weighs 7.43 tons.

What are the transport dimensions of the Hamm HD+ 70i VO?

The Hamm HD+ 70i VO has a transport length of 4.48 meters, a transport width of 1.79 meters, and a transport height of 2.89 meters.

What type of drive system does the Hamm HD+ 70i VO have in its undercarriage?

The Hamm HD+ 70i VO has an all-wheel drive system in its undercarriage.

What are the maneuverability specifications of the Hamm HD+ 70i VO tandem vibration roller?

The Hamm HD+ 70i VO features articulated-frame steering and has an outside turning radius of 4.23 meters.

What are the compaction capabilities of the Hamm HD+ 70i VO tandem vibration roller?

The Hamm HD+ 70i VO features a double vibration system operating at a frequency of 58 Hz, generates a centrifugal force of 84 kN, and has a statical line load of 25 kg/cm.

What are the roller specifications of the Hamm HD+ 70i VO tandem vibration roller?

The Hamm HD+ 70i VO has rollers that are 1.5 meters wide with a diameter of 1.14 meters.

How much is a Hamm HD+ 70i VO Tandem Vibration Roller (2019u20132025) worth?

The residual value of the Hamm HD+ 70i VO depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hamm HD+ 70i VO overview

Water Spray System

Equipment

12 V socket, 2 large working and rear view mirrors, Foldable scraper, Dashboard with displays, indicator lights and switches, Tiltable dashboard, Pressure water sprinkling with interval switch, ECO mode, Operator’s platform with entry from both sides, Speed-controlled water sprinkling system, Speed preselect, Vibration-insulated operator’s platform, Track offset, hydraulics, Spray system with spray bars front and rear, Water filtering (triple), Water tank front and rear, can be filled from both sides, Central water drain.
