HD 70 Hamm HD 70 Specifications & Technical Data (2019—2026)
Visit Hamm live at
Technical specs - HD 70 Hamm
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 7.26 t
- Transport length
- 4.34 m
- Transport width
- 1.61 m
- Transport height
- 2.94 m
- Vibration
- d
- Drive
- A
- Steering
- KL
- Travel speed
- 12.6 km/h
- Frequency
- 58 Hz
- Roller width
- 1.5 m
- Rollers Ø
- 1.14 m
- Turning radius outside
- 4.174 m
- Statical line load
- 24.5 kg/cm
- Centrifugal force
- 77 kN
- Model series
- HD
- Engine manuf.
- Deutz
- Engine type
- TD 2011 L04 W
- Engine power
- 55.4 kW
- Displacement
- 2.9 l
- Revolutions at max torque
- 2500 rpm
- No. of cylinders
- 4
- Emission level
- III A
More technical details, like: dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Hamm HD 70 FAQ
How much does the Hamm HD 70 weigh?
What are the transport dimensions of the Hamm HD 70 tandem vibration roller?
What is the travel speed of the Hamm HD 70 tandem vibration roller?
What type of drive system does the undercarriage of the Hamm HD 70 have?
What are the maneuverability specifications of the Hamm HD 70 tandem vibration roller?
What are the compaction capabilities of the Hamm HD 70 tandem vibration roller?
What are the roller dimensions of the Hamm HD 70 tandem vibration roller?
How much is a Hamm HD 70 Tandem Vibration Roller (2019u20132025) worth?
