HD+ 140i VV Hamm HD+ 140i VV Specifications & Technical Data (2016—2021)

Weight: 12.85t – Transport length: 5.3m – Transport width: 2.26m – Transport height: 2.98m – Vibration: d – Drive: E

Rollers Tandem Vibration Rollers Hamm HD+ 140i VV

HD+ 140i VV

Years of manufacture: 2016—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - HD+ 140i VV Hamm

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 12.85 t

Transport length: 5.3 m

Transport width: 2.26 m

Transport height: 2.98 m

Vibration: d

Drive: E

Steering: KL

Travel speed: 12 km/h

Frequency: 50 Hz

Roller width: 2.14 m

Rollers Ø: 1.4 m

Turning radius outside: 6.2 m

Statical line load: 30.1 kg/cm

Centrifugal force: 180 kN

Model series: HD+

Engine manuf.: Deutz

Engine type: TCD4.1 L4

Engine power: 115 kW

Displacement: 4.1 l

Max. torque: 609/1600 Nm

No. of cylinders: 4

Emission level: IV

More technical details, like: dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

HD+ 140i VV Hamm Specification for Europe (EN)

Hamm HD+ 140i VV FAQ

When was the Hamm HD+ 140i VV manufactured?

The Hamm HD+ 140i VV was manufactured from 2016 to 2021.

How much does the Hamm HD+ 140i VV weigh?

The Hamm HD+ 140i VV weighs 12.85 tons.

What are the transport dimensions of the Hamm HD+ 140i VV tandem vibration roller?

The Hamm HD+ 140i VV has a transport length of 5.3 meters, a transport width of 2.26 meters, and a transport height of 2.98 meters.

What is the travel speed of the Hamm HD+ 140i VV tandem vibration roller?

The Hamm HD+ 140i VV has a travel speed of 12 km/h.

What type of drive does the Hamm HD+ 140i VV have in its undercarriage?

The Hamm HD+ 140i VV has a simple drive in its undercarriage.

What are the maneuverability specifications of the Hamm HD+ 140i VV tandem vibration roller?

The Hamm HD+ 140i VV features articulated-frame steering and has an outside turning radius of 6.2 meters.

What are the compaction capabilities of the Hamm HD+ 140i VV tandem vibration roller?

The Hamm HD+ 140i VV features a double vibration system, operates at a frequency of 50 Hz, generates a centrifugal force of 180 kN, and has a statical line load of 30.1 kg/cm.

What are the roller specifications of the Hamm HD+ 140i VV tandem vibration roller?

The Hamm HD+ 140i VV has rollers that are 2.14 meters wide with a diameter of 1.4 meters.

How much is a Hamm HD+ 140i VV Tandem Vibration Roller (2016u20132021) worth?

The residual value of the Hamm HD+ 140i VV depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hamm HD+ 140i VV overview

Hamm HD+ 140i VV features overview

Highlights hd+

3-point articulation for even weight distribution and excellent on-centre feel. Operating concept Easy Drive. Electronic machine management Hammtronic. Excellent view of the machine and the construction site. Track offset for comfortable start up, moving away and compacting at curb edges.

Water Spray System

Equipment

12 V socket, 2 large working and rear view mirrors, Foldable scraper, Operating concept Easy Drive, Pressure water sprinkling with interval switch, ECO mode, Operator's platform with entry from both sides, Speed-controlled water sprinkling system, Speed preselect, Vibration-isolated operator's platform, Track offset, hydraulic, Spray system with spray bars front and rear, Water filtering (triple), Water tank front and rear, can be filled from both sides, Central water drain, Handrails on the operator's platform.
