Hamm HD 10e VO Specifications & Technical Data (2023-2026)

Technical specs - HD 10e VO Hamm

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.68 t

Transport length: 2.53 m

Transport width: 1.11 m

Transport height: 2.48 m

Steering: KL

Travel speed: 10 km/h

Frequency: 65 Hz

Roller width: 1 m

Rollers Ø: 0.72 m

Statical line load: 13.04 kg/cm

Centrifugal force: 35.9 kN

More technical details, like: vibration, drive, turning radius outside, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: vibration, drive, turning radius outside, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Hamm HD 10e VO FAQ

When was the Hamm HD 10e VO manufactured?

The Hamm HD 10e VO was first produced in 2023.

How much does the Hamm HD 10e VO weigh?

The Hamm HD 10e VO weighs 2.68 tons.

What are the transport dimensions of the Hamm HD 10e VO tandem vibration roller?

The Hamm HD 10e VO has a transport length of 2.53 meters, a transport width of 1.11 meters, and a transport height of 2.48 meters.

What is the travel speed of the Hamm HD 10e VO tandem vibration roller?

The Hamm HD 10e VO has a travel speed of 10 km/h.

What type of steering system does the Hamm HD 10e VO use for maneuverability?

The Hamm HD 10e VO uses an articulated-frame steering system for maneuverability.

What are the compaction capabilities of the Hamm HD 10e VO tandem vibration roller?

The Hamm HD 10e VO tandem vibration roller operates at a frequency of 65 Hz, generates a centrifugal force of 35.9 kN, and has a statical line load of 13.04 kg/cm.

What are the roller specifications of the Hamm HD 10e VO tandem vibration roller?

The Hamm HD 10e VO has rollers that are 1 meter wide with a diameter of 0.72 meters.

How much is a Hamm HD 10e VO Tandem Vibration Roller (2023u20132025) worth?

The residual value of the Hamm HD 10e VO depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
