DV+ 90i VS-OS Hamm DV+ 90i VS-OS Specifications & Technical Data (2021—2026)
Visit Hamm live at
Technical specs - DV+ 90i VS-OS Hamm
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 10.06 t
- Transport length
- 4.45 m
- Transport width
- 1.86 m
- Transport height
- 2.95 m
- Steering
- AL
- Travel speed
- 11 km/h
- Frequency
- 50 Hz
- Roller width
- 1.68 m
- Rollers Ø
- 1.2 m
- Statical line load
- 29.2 kg/cm
- Centrifugal force
- 84 kN
- Model series
- DV+
- Engine manuf.
- Deutz
- Engine type
- TCD3.6 L4
- Engine power
- 74.4 kW
- Displacement
- 3.6 l
- Revolutions at max torque
- 2000 rpm
- Max. torque
- 410/1600 Nm
- No. of cylinders
- 4
- Emission level
- EU V
More technical details, like: vibration, drive, turning radius outside, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
Yes
- Oscillation
-
Yes
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Hamm DV+ 90i VS-OS FAQ
How much does the Hamm DV+ 90i VS-OS weigh?
What are the transport dimensions of the Hamm DV+ 90i VS-OS?
What is the travel speed of the Hamm DV+ 90i VS-OS tandem vibration roller?
What type of steering does the Hamm DV+ 90i VS-OS have?
What are the compaction capabilities of the Hamm DV+ 90i VS-OS tandem vibration roller?
What are the roller specifications of the Hamm DV+ 90i VS-OS tandem vibration roller?
How much is a Hamm DV+ 90i VS-OS Tandem Vibration Roller (2021u20132025) worth?
