Caterpillar CD54B Specifications & Technical Data (2017-2026)

Technical specs - CD54B Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.12 t

Transport length: 4.32 m

Transport width: 1.87 m

Transport height: 2.99 m

Travel speed: 11 km/h

Frequency: 42 Hz

Roller width: 1.7 m

Rollers Ø: 1.198 m

Statical line load: 30 kg/cm

Centrifugal force: 107 kN

Model series: CD

Engine manuf.: Caterpillar

Engine type: C3.4B

Engine power: 75 kW

Displacement: 3.4 l

Max. torque: 420/1400 Nm

Cylinder bore x stroke: 99x110 mm

Emission level: III b

More technical details, like: vibration, drive, steering, turning radius outside, dimension lxwxh, revolutions at max torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download specalog and datasheets (PDF)

Caterpillar CD54B FAQ

When was the Caterpillar CD54B manufactured?

The Caterpillar CD54B was first produced in 2017.

How much does the Caterpillar CD54B weigh?

The Caterpillar CD54B weighs 10.12 tons.

What are the transport dimensions of the Caterpillar CD54B tandem vibration roller?

The Caterpillar CD54B has a transport length of 4.32 meters, a transport width of 1.87 meters, and a transport height of 2.99 meters.

What is the travel speed of the Caterpillar CD54B tandem vibration roller?

The Caterpillar CD54B tandem vibration roller has a travel speed of 11 km/h.

What are the compaction capabilities of the Caterpillar CD54B tandem vibration roller?

The Caterpillar CD54B tandem vibration roller operates at a frequency of 42 Hz, generates a centrifugal force of 107 kN, and has a statical line load of 30 kg/cm.

What are the roller specifications of the Caterpillar CD54B tandem vibration roller?

The Caterpillar CD54B has rollers that are 1.7 meters wide with a diameter of 1.198 meters.

How much is a Caterpillar CD54B Tandem Vibration Roller (2017u20132025) worth?

The residual value of the Caterpillar CD54B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
