Caterpillar CB10 Specifications & Technical Data (2017-2026)

Technical specs - CB10 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.67 t

Transport length: 4.57 m

Transport width: 1.87 m

Transport height: 2.98 m

Travel speed: 12 km/h

Frequency: 42 Hz

Roller width: 1.7 m

Statical line load: 31.5 kg/cm

Model series: CB

Engine manuf.: Caterpillar

Engine type: C4.4 Acert

Engine power: 98 kW

Revolutions at max torque: 2200 rpm

No. of cylinders: 4

More technical details, like: vibration, drive, steering, rollers Ø, turning radius outside, centrifugal force, dimension lxwxh, displacement, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download specalog and datasheets (PDF)

CB10 Caterpillar Specification for Europe (EN)

Caterpillar CB10 FAQ

When was the Caterpillar CB10 manufactured?

The Caterpillar CB10 was first produced in 2017.

How much does the Caterpillar CB10 weigh?

The Caterpillar CB10 weighs 10.67 tons.

What are the transport dimensions of the Caterpillar CB10 tandem vibration roller?

The Caterpillar CB10 has a transport length of 4.57 meters, a transport width of 1.87 meters, and a transport height of 2.98 meters.

What is the travel speed of the Caterpillar CB10 tandem vibration roller?

The Caterpillar CB10 has a travel speed of 12 km/h.

What are the compaction capabilities of the Caterpillar CB10 tandem vibration roller?

The Caterpillar CB10 operates at a vibration frequency of 42 Hz and has a statical line load of 31.5 kg/cm.

What is the roller width of the Caterpillar CB10 tandem vibration roller?

The Caterpillar CB10 tandem vibration roller has a roller width of 1.7 meters.

How much is a Caterpillar CB10 Tandem Vibration Roller (2017u20132025) worth?

The residual value of the Caterpillar CB10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
