Case DV207 Specifications & Technical Data (2012-2026)

Technical specs - DV207 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.36 t

Transport length: 4.41 m

Transport width: 1.54 m

Transport height: 2.95 m

Frequency: 52 Hz

Roller width: 1.45 m

Statical line load: 25.9 kg/cm

Centrifugal force: 65 kN

Engine manuf.: Cummins

Engine type: BTA3.3-C80

Engine power: 60 kW

More technical details, like: vibration, drive, steering, travel speed, rollers Ø, turning radius outside, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: vibration, drive, steering, travel speed, rollers Ø, turning radius outside, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Case DV207 FAQ

When was the Case DV207 manufactured?

The Case DV207 was first produced in 2012.

How much does the Case DV207 weigh?

The Case DV207 weighs 7.36 tons.

What are the transport dimensions of the Case DV207 tandem vibration roller?

The Case DV207 has a transport length of 4.41 meters, a transport width of 1.54 meters, and a transport height of 2.95 meters.

What are the compaction capabilities of the Case DV207 tandem vibration roller?

The Case DV207 tandem vibration roller operates at a frequency of 52 Hz, generates a centrifugal force of 65 kN, and has a statical line load of 25.9 kg/cm.

What is the roller width of the Case DV207 tandem vibration roller?

The Case DV207 tandem vibration roller has a roller width of 1.45 meters.

How much is a Case DV207 Tandem Vibration Roller (2012u20132025) worth?

The residual value of the Case DV207 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
