Case DV204 Specifications & Technical Data (2007-2026)

Technical specs - DV204 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.5 t

Transport length: 2.64 m

Transport width: 1.36 m

Transport height: 2.68 m

Frequency: 62 Hz

Roller width: 1.3 m

Centrifugal force: 29.4 kN

Engine manuf.: Deutz

Engine type: F3L1011F

Engine power: 27.6 kW

More technical details, like: vibration, drive, steering, travel speed, rollers Ø, turning radius outside, statical line load, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: vibration, drive, steering, travel speed, rollers Ø, turning radius outside, statical line load, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Case DV204 FAQ

When was the Case DV204 manufactured?

The Case DV204 was first produced in 2007.

How much does the Case DV204 weigh?

The Case DV204 weighs 3.5 tons.

What are the transport dimensions of the Case DV204 tandem vibration roller?

The Case DV204 has a transport length of 2.64 meters, a transport width of 1.36 meters, and a transport height of 2.68 meters.

What are the compaction capabilities of the Case DV204 tandem vibration roller?

The Case DV204 tandem vibration roller operates at a frequency of 62 Hz and generates a centrifugal force of 29.4 kN.

What is the roller width of the Case DV204 tandem vibration roller?

The roller width of the Case DV204 tandem vibration roller is 1.3 meters.

How much is a Case DV204 Tandem Vibration Roller (2007u20132025) worth?

The residual value of the Case DV204 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
