Case DV201 Specifications & Technical Data (2007-2026)

Technical specs - DV201 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.5 t

Transport length: 2.64 m

Transport width: 1.09 m

Transport height: 2.68 m

Frequency: 53 Hz

Roller width: 1 m

Rollers Ø: 0.74 m

Centrifugal force: 28.5 kN

Engine manuf.: Deutz

Engine type: D2011 L2

Engine power: 23 kW

More technical details, like: vibration, drive, steering, travel speed, turning radius outside, statical line load, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: vibration, drive, steering, travel speed, turning radius outside, statical line load, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Case DV201 FAQ

When was the Case DV201 manufactured?

The Case DV201 was first produced in 2007.

How much does the Case DV201 weigh?

The Case DV201 weighs 2.5 tons.

What are the transport dimensions of the Case DV201 tandem vibration roller?

The Case DV201 has a transport length of 2.64 meters, a transport width of 1.09 meters, and a transport height of 2.68 meters.

What are the compaction capabilities of the Case DV201 tandem vibration roller?

The Case DV201 tandem vibration roller operates at a frequency of 53 Hz and generates a centrifugal force of 28.5 kN.

What are the roller specifications of the Case DV201 tandem vibration roller?

The Case DV201 tandem vibration roller has rollers that are 1 meter wide with a diameter of 0.74 meters.

How much is a Case DV201 Tandem Vibration Roller (2007u20132025) worth?

The residual value of the Case DV201 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
