Bomag BW 62 H E-Start Specifications & Technical Data (2006-2011)

Technical specs - BW 62 H E-Start Bomag

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 0.57 t

Transport length: 2.2 m

Transport width: 0.762 m

Transport height: 0.96 m

Vibration: d

Drive: A

Travel speed: 5.5 km/h

Frequency: 55 Hz

Roller width: 0.6 m

Rollers Ø: 0.4 m

Statical line load: 5 kg/cm

Model series: BW

Engine manuf.: Jatu

Engine type: 1 D 41 S

Engine power: 53 kW

Revolutions at max torque: 2800 rpm

More technical details, like: steering, turning radius outside, centrifugal force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Bomag BW 62 H E-Start FAQ

When was the Bomag BW 62 H E-Start manufactured?

The Bomag BW 62 H E-Start was manufactured from 2006 to 2011.

How much does the Bomag BW 62 H E-Start weigh?

The Bomag BW 62 H E-Start weighs 0.57 tons.

What are the transport dimensions of the Bomag BW 62 H E-Start?

The Bomag BW 62 H E-Start has a transport length of 2.2 meters, a transport width of 0.76 meters, and a transport height of 0.96 meters.

What is the travel speed of the Bomag BW 62 H E-Start?

The Bomag BW 62 H E-Start has a travel speed of 5.5 km/h.

What type of drive system does the undercarriage of the Bomag BW 62 H E-Start have?

The undercarriage of the Bomag BW 62 H E-Start features an all-wheel drive system.

What are the compaction capabilities of the Bomag BW 62 H E-Start tandem vibration roller?

The Bomag BW 62 H E-Start features a double vibration system operating at a frequency of 55 Hz and has a statical line load of 5 kg/cm.

What are the roller specifications of the Bomag BW 62 H E-Start?

The Bomag BW 62 H E-Start has rollers that are 0.6 meters wide with a diameter of 0.4 meters.

How much is a Bomag BW 62 H E-Start Tandem Vibration Roller (2006u20132011) worth?

The residual value of the Bomag BW 62 H E-Start depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
