Technical specs - BW 191 ADO-5 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 13.1 t
- Transport length
- 5.3 m
- Transport width
- 2.178 m
- Transport height
- 3.093 m
- Vibration
- d
- Drive
- A
- Steering
- KL
- Travel speed
- 12 km/h
- Frequency
- 55 Hz
- Roller width
- 2 m
- Rollers Ø
- 1.4 m
- Turning radius outside
- 5.19 m
- Statical line load
- 33.3 kg/cm
- Centrifugal force
- 129 kN
- Model series
- BW
- Engine manuf.
- Deutz
- Engine type
- TCD4.1 L04
- Engine power
- 105 kW
- Revolutions at max torque
- 2300 rpm
- No. of cylinders
- 4
- Emission level
- IV/Tier 4f
More technical details, like: dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
Yes
- Oscillation
-
Yes
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
