BW 154 APO-5 Bomag BW 154 APO-5 Specifications & Technical Data (2022—2026)

Weight: 7.94t – Transport length: 3.99m – Transport width: 1.68m – Transport height: 3.02m – Vibration: d – Drive: A

Rollers Tandem Vibration Rollers Bomag BW 154 APO-5
Rollers Tandem Vibration Rollers Bomag BW 154 APO-5
Rollers Tandem Vibration Rollers Bomag BW 154 APO-5
Rollers Tandem Vibration Rollers Bomag BW 154 APO-5
Rollers Tandem Vibration Rollers Bomag BW 154 APO-5
Rollers Tandem Vibration Rollers Bomag BW 154 APO-5
Rollers Tandem Vibration Rollers Bomag BW 154 APO-5
Rollers Tandem Vibration Rollers Bomag BW 154 APO-5

Visit Bomag live at

Technical specs - BW 154 APO-5 Bomag

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.94 t
Transport length
3.99 m
Transport width
1.68 m
Transport height
3.02 m
Vibration
d
Drive
A
Steering
KL
Travel speed
11 km/h
Frequency
47 Hz
Roller width
1.5 m
Turning radius outside
2.95 m
Statical line load
27.7 kg/cm
Centrifugal force
101 kN
Model series
BW
Engine manuf.
Kubota
Engine type
V3307 -T
Engine power
55.4 kW
Revolutions at max torque
2400 rpm
No. of cylinders
4
Emission level
Stage V / TIER4f

More technical details, like: rollers Ø, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Oscillation
Yes
Compression control
No
Aircondition
Yes

Download datasheets (PDF)

Bomag BW 154 APO-5 FAQ

When was the Bomag BW 154 APO-5 manufactured?

The Bomag BW 154 APO-5 was first produced in 2022.

How much does the Bomag BW 154 APO-5 weigh?

The Bomag BW 154 APO-5 weighs 7.94 tons.

What are the transport dimensions of the Bomag BW 154 APO-5?

The Bomag BW 154 APO-5 has a transport length of 3.99 meters, a transport width of 1.68 meters, and a transport height of 3.02 meters.

What is the travel speed of the Bomag BW 154 APO-5 tandem vibration roller?

The Bomag BW 154 APO-5 has a travel speed of 11 km/h.

What type of drive system does the undercarriage of the Bomag BW 154 APO-5 have?

The undercarriage of the Bomag BW 154 APO-5 features an all-wheel drive system.

What are the maneuverability specifications of the Bomag BW 154 APO-5?

The Bomag BW 154 APO-5 has an articulated-frame steering system and an outside turning radius of 2.95 meters.

What are the compaction capabilities of the Bomag BW 154 APO-5 tandem vibration roller?

The Bomag BW 154 APO-5 features a double vibration system, operates at a frequency of 47 Hz, generates a centrifugal force of 101 kN, and has a statical line load of 27.7 kg/cm.

What is the roller width of the Bomag BW 154 APO-5?

The Bomag BW 154 APO-5 has a roller width of 1.5 meters.

How much is a Bomag BW 154 APO-5 Tandem Vibration Roller (2022u20132025) worth?

The residual value of the Bomag BW 154 APO-5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
