BW 154 AP-5 AM Bomag BW 154 AP-5 AM Specifications & Technical Data (2022—2026)

Weight: 7.3t – Transport length: 3.99m – Transport width: 1.68m – Transport height: 3.02m – Vibration: d – Drive: A

Rollers Tandem Vibration Rollers Bomag BW 154 AP-5 AM

Visit Bomag live at

BW 154 AP-5 AM

Years of manufacture: 2022—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - BW 154 AP-5 AM Bomag

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.3 t

Transport length: 3.99 m

Transport width: 1.68 m

Transport height: 3.02 m

Vibration: d

Drive: A

Steering: KL

Travel speed: 7.3 km/h

Frequency: 47 Hz

Roller width: 1.5 m

Turning radius outside: 2.95 m

Statical line load: 25 kg/cm

Centrifugal force: 101 kN

Model series: BW

Engine manuf.: Kubota

Engine type: V3307 -T

Engine power: 55.4 kW

Revolutions at max torque: 2400 rpm

No. of cylinders: 4

Emission level: Stage V / TIER4f

More technical details, like: rollers Ø, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: Yes
Compression control: No
Aircondition: Yes

Download datasheets (PDF)

Bomag BW 154 AP-5 AM FAQ

When was the Bomag BW 154 AP-5 AM manufactured?

The Bomag BW 154 AP-5 AM was first produced in 2022.

How much does the Bomag BW 154 AP-5 AM weigh?

The Bomag BW 154 AP-5 AM weighs 7.3 tons.

What are the transport dimensions of the Bomag BW 154 AP-5 AM?

The Bomag BW 154 AP-5 AM has a transport length of 3.99 meters, a transport width of 1.68 meters, and a transport height of 3.02 meters.

What is the travel speed of the Bomag BW 154 AP-5 AM?

The Bomag BW 154 AP-5 AM has a travel speed of 7.3 km/h.

What type of drive system does the Bomag BW 154 AP-5 AM have in its undercarriage?

The Bomag BW 154 AP-5 AM has an all-wheel drive system in its undercarriage.

What are the maneuverability specifications of the Bomag BW 154 AP-5 AM tandem vibration roller?

The Bomag BW 154 AP-5 AM has an articulated-frame steering system and an outside turning radius of 2.95 meters.

What are the compaction capabilities of the Bomag BW 154 AP-5 AM tandem vibration roller?

The Bomag BW 154 AP-5 AM features a double vibration system, operates at a frequency of 47 Hz, generates a centrifugal force of 101 kN, and has a statical line load of 25 kg/cm.

What is the roller width of the Bomag BW 154 AP-5 AM tandem vibration roller?

The Bomag BW 154 AP-5 AM tandem vibration roller has a roller width of 1.5 meters.

How much is a Bomag BW 154 AP-5 AM Tandem Vibration Roller (2022u20132025) worth?

The residual value of the Bomag BW 154 AP-5 AM depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
