Technical specs - BW 154 AP-5 Bomag

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.1 t
Transport length
3.99 m
Transport width
1.68 m
Transport height
3.02 m
Vibration
d
Drive
A
Steering
KL
Travel speed
11 km/h
Frequency
60 Hz
Roller width
1.5 m
Turning radius outside
2.95 m
Statical line load
23.7 kg/cm
Centrifugal force
111 kN
Model series
BW
Engine manuf.
Kubota
Engine type
V3307 -T
Engine power
55.4 kW
Revolutions at max torque
2400 rpm
No. of cylinders
4
Emission level
Stage V / TIER4f

More technical details, like: rollers Ø, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Oscillation
No
Compression control
No
Aircondition
Yes

Download datasheets (PDF)

Bomag BW 154 AP-5 FAQ

When was the Bomag BW 154 AP-5 manufactured?

The Bomag BW 154 AP-5 was first produced in 2022.

How much does the Bomag BW 154 AP-5 weigh?

The Bomag BW 154 AP-5 weighs 7.1 tons.

What are the transport dimensions of the Bomag BW 154 AP-5 tandem vibration roller?

The Bomag BW 154 AP-5 has transport dimensions of 3.99 meters in length, 1.68 meters in width, and 3.02 meters in height.

What is the travel speed of the Bomag BW 154 AP-5 tandem vibration roller?

The Bomag BW 154 AP-5 has a travel speed of 11 km/h.

What type of drive system does the Bomag BW 154 AP-5 have in its undercarriage?

The Bomag BW 154 AP-5 features an all-wheel drive system in its undercarriage.

What are the maneuverability specifications of the Bomag BW 154 AP-5 tandem vibration roller?

The Bomag BW 154 AP-5 has an articulated-frame steering system and an outside turning radius of 2.95 meters.

What are the compaction capabilities of the Bomag BW 154 AP-5 tandem vibration roller?

The Bomag BW 154 AP-5 features a double vibration system operating at a frequency of 60 Hz, generates a centrifugal force of 111 kN, and has a statical line load of 23.7 kg/cm.

What is the roller width of the Bomag BW 154 AP-5 tandem vibration roller?

The Bomag BW 154 AP-5 tandem vibration roller has a roller width of 1.5 meters.

How much is a Bomag BW 154 AP-5 Tandem Vibration Roller (2022u20132025) worth?

The residual value of the Bomag BW 154 AP-5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
