BW 154 AP-5 Bomag BW 154 AP-5 Specifications & Technical Data (2022—2026)

Weight: 7.1t – Transport length: 3.99m – Transport width: 1.68m – Transport height: 3.02m – Vibration: d – Drive: A

Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5
Rollers Tandem Vibration Rollers Bomag BW 154 AP-5

Visit Bomag live at

Technical specs - BW 154 AP-5 Bomag

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.1 t
Transport length
3.99 m
Transport width
1.68 m
Transport height
3.02 m
Vibration
d
Drive
A
Steering
DSL
Travel speed
11 km/h
Frequency
60 Hz
Roller width
1.5 m
Rollers Ø
1.1 m
Statical line load
23.7 kg/cm
Centrifugal force
101 kN
Model series
BW
Engine manuf.
Kubota
Engine type
V3307 CR-T
Engine power
55.4 kW
Displacement
3.3 l
Revolutions at max torque
2400 rpm
No. of cylinders
4
Emission level
V/Tier 4f

More technical details, like: turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
Yes
Oscillation
No
Compression control
No
Aircondition
No

Download datasheets (PDF)

Bomag BW 154 AP-5 FAQ

When was the Bomag BW 154 AP-5 manufactured?

The Bomag BW 154 AP-5 was first produced in 2022.

How much does the Bomag BW 154 AP-5 weigh?

The Bomag BW 154 AP-5 weighs 7.1 tons.

What are the transport dimensions of the Bomag BW 154 AP-5?

The Bomag BW 154 AP-5 has a transport length of 3.99 meters, a transport width of 1.68 meters, and a transport height of 3.02 meters.

What is the travel speed of the Bomag BW 154 AP-5?

The Bomag BW 154 AP-5 has a travel speed of 11 km/h.

What type of drive system does the Bomag BW 154 AP-5 have in its undercarriage?

The Bomag BW 154 AP-5 has an all-wheel drive system in its undercarriage.

What type of steering system does the Bomag BW 154 AP-5 use for maneuverability?

The Bomag BW 154 AP-5 uses a double center pivot plate steering system for maneuverability.

What are the compaction capabilities of the Bomag BW 154 AP-5 tandem vibration roller?

The Bomag BW 154 AP-5 features a double vibration system, operates at a frequency of 60 Hz, generates a centrifugal force of 101 kN, and has a statical line load of 23.7 kg/cm.

What are the roller specifications of the Bomag BW 154 AP-5?

The Bomag BW 154 AP-5 has rollers that are 1.5 meters wide with a diameter of 1.1 meters.

How much is a Bomag BW 154 AP-5 Tandem Vibration Roller (2022u20132025) worth?

The residual value of the Bomag BW 154 AP-5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
