AV 70-2 K Ammann AV 70-2 K Specifications & Technical Data (2010—2018)

Weight: 7.32t – Transport length: 3.95m – Transport width: 1.59m – Transport height: 2.9m – Vibration: e – Steering: DSL

AV 70-2 K

Years of manufacture: 2010—2018

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AV 70-2 K Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.32 t

Transport length: 3.95 m

Transport width: 1.59 m

Transport height: 2.9 m

Vibration: e

Steering: DSL

Travel speed: 9 km/h

Frequency: 50 Hz

Roller width: 1.45 m

Rollers Ø: 1.15 m

Turning radius outside: 4.277 m

Statical line load: 24.6 kg/cm

Model series: AV

Engine manuf.: Cummins

Engine type: 4BT3.3-C74

Engine power: 55 kW

More technical details, like: drive, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Ammann AV 70-2 K FAQ

When was the Ammann AV 70-2 K manufactured?

The Ammann AV 70-2 K was manufactured from 2010 to 2018.

How much does the Ammann AV 70-2 K weigh?

The Ammann AV 70-2 K weighs 7.32 tons.

What are the transport dimensions of the Ammann AV 70-2 K tandem vibration roller?

The Ammann AV 70-2 K has a transport length of 3.95 meters, a transport width of 1.59 meters, and a transport height of 2.9 meters.

What is the travel speed of the Ammann AV 70-2 K tandem vibration roller?

The Ammann AV 70-2 K has a travel speed of 9 km/h.

What are the maneuverability specifications of the Ammann AV 70-2 K tandem vibration roller?

The Ammann AV 70-2 K has a turning radius of 4.277 meters and features double center pivot plate steering.

What are the compaction capabilities of the Ammann AV 70-2 K tandem vibration roller?

The Ammann AV 70-2 K features a single vibration system operating at a frequency of 50 Hz and has a statical line load of 24.6 kg/cm.

What are the roller specifications of the Ammann AV 70-2 K tandem vibration roller?

The Ammann AV 70-2 K has rollers that are 1.45 meters wide with a diameter of 1.15 meters.
